Integrated touch.
The 1915L desktop LCD touch monitor is equipped with IntelliTouch® surface acoustic wave (SAW), with a dual serial/ USB touch interface.
Flexible mounting.
The Elo 1915L offers multiple mounting options to ensure installation flexibility including: wall- and pole-mount via standard VESA mount patterns as well as tabletop accommodations with the use of the desktop stand. Capped through-mount holes on the base of the touch monitor ensure table-top security.
Commercial grade.
The 1915L touchscreen monitor delivers the quality and reliability Elo is known for and is backed by our three-year standard warranty. All our products go through rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF.
Other features.
- Affordability paired with Elo quality OR Consumer-grade pricing with Elo commercial-grade reliability
- Designed for touch features such as a stable tilt stand
- Long-lasting product cycle
- Sealed touchscreen against dirt, dust and liquid
- Dual serial/USB interface
- Removable stand and VESA mounting option
- Mounting holes on stand bottom for tabletop security
- Controls on the side rather than the front, plus lockout function for public use
- Digital on-screen display (OSD)
- Worldwide agency approvals
- Three-year standard warranty
Specifications
Part Number(s)
IntelliTouch – E266835
Enclosure Colour
Dark Gray
Touch Technology & Capacity
SAW (IntelliTouch® Surface Acoustic Wave) – Single Touch
Diagonal Size
19” diagonal, Active matrix TFT LCD (LED)
Aspect Ratio
5:4
Active Area (mm)
376.3mm x 301.1mm
Resolution
1280 x 1024
Other Supported Resolutions
1280 x 1024 at 60 or 75 Hz
1152 x 864 at 75 Hz
1024 x 768 at 60, 65, 70 or 75 Hz
832 x 624 at 75 Hz (Mac)
800 x 600 at 56, 60, 72 or 75 Hz
720 x 400 at 70 Hz
720 x 350 at 70 Hz
640 x 480 at 60, 66, 72 or 75 Hz
Viewing Angle
Horizontal: ±85° or 170° total / Vertical: ±80° or 160° total
Number of Colours
16.7 million
Brightness (typical)
LCD panel: 250 nits
IntelliTouch: 225 nits
Response Time-total (typical)
5 msec
Contrast Ratio
1000:1
Input Video Format
Analog VGA
Input Video Signal Connector
Mini D-Sub 15-Pin VGA type
Power Supply
Internal AC, power cable-C5 type, optional external DC (power brick)
Monitor input power signal specifications: 12VDC +/- 5%
Input Voltage
100-240VAC, 50/60Hz
Input Connector
Coaxial power jack (2.0mm (+0.0 -0.1mm) pin outer diameter, 6.4mm (+/- 0.3mm) barrel inner diameter, 8.8mm (+/- 0.3mm) Barrel depth)
Input Frequency
Horizontal: 31.5-80 kHz
Vertical: 56.3-75 Hz
Adapter Input Connector
IEC 60320 C14
Adapter Input Voltage Range
100-240VAC, 50/60Hz
Power Consumption (Typical)
ON (monitor + 100V AC): 16.25W
SLEEP (monitor + 100V AC): 1.19W
OFF (monitor + 100V AC): 0.63W
On Screen Display
Controls (side): menu, up, down, select, power
Settings: contrast, brightness, H/V position, RGB (color temp), clock, phase, recall
Languages: English, German, Spanish, Japanese, French
Lockouts: power, user controls
Monitor Dimensions (with Stand)
429mm x 379mm x 207mm
Shipping Box Dimensions
540mm x 495mm x 285mm
Weight (with Stand)
7.9 kg
Shipping Weight (with Stand)
11.7 kg
Operating Temperature
0°C to 40°C
Storage Temperature
-20°C to 60°C
Humidity
Operating: 20% to 80%; Storage: 10% to 90%
Sealability
Touchscreen sealed to bezel; Touchscreen sealed to LCD
MTBF
50,000 hours demonstrated
Stand Options
Tilt, remove
Mounting Options
100 mm VESA mount
Threaded-through mounting holes, under stand
Other Features
Security lock receptacle
Warranty
3-year
Regulatory approvals and declarations
UL, cUL, FCC, CE, VCCI, IC, RCM, Argentina S Mark
What’s in the Box
User Guide CD
Quick Installation Guide (QIG)
AC Power Cord Mickey 1.8M BK EU/KOREA
AC Power Cord UL/SP-030+IS-034 1.8M BK
Cable A55336-000 USB A-B 1830mmBK
Cable DSUB-9PX2 1800mm BK W/PEBAG
Cable VGA PC99 1.8M BK
